No.
|
Product | Type | SOC |
CPU |
NPU |
Encode |
Decode |
Video In |
Video Out |
Internet |
High-speed |
Others |
Type/Size |
Level |
|
|
1
|
EC20 4G-LTE | Communication Module |
--
|
--
|
--
|
--
|
--
|
--
|
--
|
--
|
--
|
--
|
--
|
--
|
|
|
2
|
RG4538 GPS | Communication Module |
--
|
--
|
--
|
--
|
--
|
--
|
--
|
--
|
--
|
--
|
--
|
--
|
|
|
3
|
EC200T 4G-LET | Communication Module |
--
|
--
|
--
|
--
|
--
|
--
|
--
|
--
|
--
|
--
|
--
|
--
|
|
|
4
|
GPS & RM4538-B | Communication Module |
--
|
--
|
--
|
--
|
--
|
--
|
--
|
--
|
--
|
--
|
--
|
--
|
|
|
5
|
iCore-3568JQ |
RK3568J
|
Quad-core 1.4GHz
|
1T
|
1080P H.265
|
4K H.265
|
MIPI-CSI × 1、DVP × 1
|
HDMI2.0 × 1、MIPI-DSI × 2、eDP1.3 × 1、RGB × 1、Single LVDS × 1
|
GbE × 2、Wi-Fi6、Bluetooth、5G/4G LTE
|
USB2.0 HOST × 2、USB3.0/PCIe2.1/SATA3.0、PCIe3.0(2L) × 2
|
SDMMC × 3、SPI × 3、UART × 10、I2C × 6、PWM × 16、ADC × 7、CAN × 3
|
BTB
|
Industrial
|
|
|
|
6
|
Core-3588JD4 | Core Boards |
RK3588
|
Octa-core 2.4GHz
|
6T
|
8K H.265
|
8K H.265、8K H.264、4K AV1、1080P VP8
|
HDMI-IN × 1、MIPI-CSI × 2
|
HDMI2.1 × 1
|
GbE × 2、Bluetooth、5G/4G LTE 、Wi-Fi6
|
USB3.0 OTG × 2、USB3.0 HOST × 1、USB2.0 HOST × 2
|
SDMMC × 1、PWM × 15、I2C × 8、UART × 7、SPI × 4、CAN × 2、ADC × 2
|
Goldfinger 260P
|
Commercial
|
|
|
7
|
Core-186JD4 | Core Boards |
CV186AH
|
Hexa-core 1.6GHz
|
6T
|
1080P H.265
|
1080P H.265
|
MIPI-CSI、Bayer RGB、BT.601
|
HDMI2.0 × 1、MIPI-DSI × 1、LVDS × 1
|
GbE × 2、2.4G/5G Wi-Fi6、5G/4G LTE 、Bluetooth5.2
|
PCIe/SATA3.0 × 2、USB3.1 HOST × 2
|
SDIO3.0 × 2、ADC × 5、I2S × 3、SPI × 4、CAN × 2、I2C × 11、UART × 9、PWM × 20
|
Goldfinger 260P
|
Commercial
|
|
|
8
|
iCore-3576Q | Core Boards |
RK3576
|
Octa-core 2.2GHz
|
6T
|
4K H.265
|
4K H.264、8K H.265
|
MIPI-CSI × 2 、MIPI-CSI D/C × 1 、DVP × 1
|
HDMI2.1 × 1、DP1.4 × 1、EBC × 1、MIPI D/C × 1 、LCDC × 1
|
GbE × 2、2.4G/5G Wi-Fi6、Bluetooth、5G/4G LTE
|
PCIe 2.1 × 2、SATA 3.1 × 2、USB3.0 OTG × 2
|
I2C × 10、I3C × 2、UART × 12、SPI × 5、PWM × 16、CAN FD × 2、SDIO3.0 × 2
|
BTB
|
Commercial
|
|
|
9
|
Core-3576JD4 | Core Boards |
RK3576
|
Octa-core 2.2GHz
|
6T
|
4K H.265
|
4K H.265、4K H.264
|
MIPI-CSI × 2 、MIPI D/C × 1 、DVP × 1
|
HDMI2.1 × 1、DP1.4 × 1、EBC × 1
|
GbE × 2、2.4G/5G Wi-Fi6、Bluetooth5.2、5G/4G LTE
|
PCIe 2.1 × 2、SATA 3.1 × 2、USB3.0 OTG × 2
|
I2C × 10、I3C × 2、UART × 12、SPI × 5、PWM × 16、CAN FD × 2、SDIO3.0 × 1
|
Goldfinger 260P
|
Commercial
|
|
|
10
|
Core-3588L | Core Boards |
RK3588
|
Octa-core 2.4GHz
|
6T
|
8K H.265
|
8K H.265、8K H.264、4K AV1、1080P VP8
|
MIPI-CSI × 4、MIPI D/C × 2、HDMI RX × 1、DVP × 1
|
HDMI2.1 TX × 2、DP1.4a × 2、MIPI-DSI × 2、BT.1120 × 1
|
GbE × 1、Wi-Fi6、Bluetooth、5G/4G LTE
|
USB3.0 OTG × 2、USB3.0 HOST × 1、USB2.0 HOST × 2、PCIe(4L) × 1、SATA3.0 × 3
|
SDIO3.0 × 1、I2C × 9、SPI × 5、UART × 10、PWM × 16、CAN × 3、ADC × 8
|
LGA506P
|
Commercial
|
|
|
11
|
Core-3588SG | Core Boards |
RK3588S
|
Octa-core 2.4GHz
|
6T
|
8K H.265
|
8K H.265、8K H.264、4K AV1、1080P VP8
|
MIPI D/C × 2、MIPI-CSI × 1
|
HDMI2.1 × 1、MIPI-DSI × 2、DP1.4 × 1、eDP1.3 × 2、BT.1120 × 1
|
GbE × 1、Wi-Fi6、Bluetooth、5G/4G LTE
|
USB3.0 OTG × 1、USB3.0 HOST × 1、USB2.0 HOST × 2、SATA3.0 × 2
|
I2C × 9、UART × 10、SPI × 5、CAN × 3、PWM × 16、SDMMC × 1、ADC × 12
|
BGA371
|
Commercial
|
|
|
12
|
Core-3588J | Core Boards |
RK3588
|
Octa-core 2.4GHz
|
6T
|
8K H.265
|
8K H.265、8K H.264、4K AV1、1080P VP8
|
HDMI-IN × 1、MIPI-CSI × 1、MIPI DC × 2 、DVP × 1
|
HDMI2.1 × 2、MIPI-DSI × 2、DP1.4 × 2、BT.1120 × 1
|
GbE × 2、Wi-Fi6、Bluetooth、5G/4G LTE
|
USB3.0 OTG × 2、USB3.0 HOST × 1、USB2.0 HOST × 2、PCIe(4L) × 1、SATA3.0 × 3
|
I2C × 9、UART × 10、SPI × 5、PWM × 16、SDMMC × 1、ADC × 7
|
Goldfinger 314P
|
Commercial
|
|
|
13
|
iCore-3588Q | Core Boards |
RK3588
|
Octa-core 2.4GHz
|
6T
|
8K H.265
|
8K H.265、8K H.264、4K AV1、1080P VP8
|
HDMI-IN × 1、MIPI-CSI × 1、MIPI DC × 2 、DVP × 1
|
HDMI2.1 × 2、MIPI-DSI × 2、DP1.4 × 2、BT.1120 × 1
|
GbE × 2、Wi-Fi6、Bluetooth、5G/4G LTE
|
USB3.0 OTG × 2、USB3.0 HOST × 1、USB2.0 HOST × 2、PCIe(4L) × 1、SATA3.0 × 3
|
I2C × 9、PWM × 16、SDMMC × 1、CAN × 3
|
BTB
|
Commercial
|
|
|
14
|
Core-3588SJD4 | Core Boards |
RK3588S
|
Octa-core 2.4GHz
|
6T
|
8K H.265
|
8K H.265、8K H.264、4K AV1、1080P VP8
|
MIPI D/C × 2、MIPI-CSI × 1、DVP × 1
|
HDMI2.1 × 1、MIPI-DSI × 2、DP1.4 × 1、BT.1120 × 1
|
GbE × 1、Wi-Fi6、Bluetooth、5G/4G LTE
|
USB3.0 OTG × 1、USB3.0 HOST × 1、USB2.0 HOST × 2、SATA3.0 × 2
|
I2C × 9、UART × 10、SPI × 5、CAN × 3、PWM × 16、ADC × 12
|
Goldfinger 260P
|
Commercial
|
|
|
15
|
Core-3568J | Core Boards |
RK3568B2
|
Quad-core 2.0GHz
|
1T
|
1080P H.265
|
4K H.265
|
MIPI-CSI × 1
|
HDMI2.0 × 1、MIPI-DSI × 2、eDP1.3 × 1
|
GbE × 2、2.4G/5G Wi-Fi6
|
USB2.0 HOST × 2、USB3.0/PCIe2.1/SATA3.0、PCIe3.0(2L) × 2
|
SDMMC × 3、SPI × 3、UART × 10、I2C × 6、I2S × 2、PWM × 16、ADC × 7、CAN × 3
|
Goldfinger 314P
|
Commercial
|
|
|
16
|
Core-3399J | Core Boards |
RK3399
|
Hexa-core 1.8GHz
|
--
|
1080P H.264、1080P AVC
|
4K H.265、4K H.264、1080P VC-1
|
MIPI-CSI × 2、DVP × 1
|
HDMI2.0 × 1、MIPI-DSI × 1、eDP1.3 × 1、DP1.2 × 1
|
GbE × 1、2.4G/5G Wi-Fi、Bluetooth、3G/4G LTE
|
PCIe2.1 × 1、USB3.0 OTG × 2、USB2.0 HOST × 2
|
I2C × 8、SPI × 5、UART × 5、PWM × 5、SDMMC × 1、ADC × 5
|
Goldfinger 314P
|
Commercial
|
|
|
17
|
Core-3399-JD4 | Core Boards |
RK3399
|
Hexa-core 1.8GHz
|
--
|
1080P H.264、1080P AVC
|
4K H.265、4K H.264、1080P VC-1
|
MIPI-CSI × 2
|
HDMI2.0 × 1、MIPI-DSI × 1、eDP1.3 × 1、DP1.2 × 1
|
GbE × 1、2.4G/5G Wi-Fi、Bluetooth、3G/4G LTE
|
PCIe2.1 × 1、USB3.0 OTG × 2、USB2.0 HOST × 2
|
I2S × 2、I2C × 8、SPI × 5、PWM × 3、UART × 5、ADC × 4
|
Goldfinger 240P
|
Commercial
|
|
|
18
|
Core-1126-JD4 | Core Boards |
RV1126
|
Quad-core 1.5GHz
|
2T
|
4K H.265
|
4K H.265
|
MIPI-CSI × 2、DVP × 1
|
MIPI-DSI × 1
|
GbE × 1、2.4G/5G Wi-Fi、Bluetooth、4G/3G
|
USB2.0 HOST × 1、USB2.0 OTG × 1
|
SPI × 2、UART × 6、I2C × 6、PWM × 4、CAN × 1
|
Goldfinger 260P
|
Commercial
|
|
|
19
|
iCore-3562JQ | Core Boards |
RK3562J
|
Quad-core 1.8GHz
|
1T
|
1080P H.264
|
4K H.265、1080P H.264
|
MIPI-CSI × 2
|
LVDS × 1、RGB × 1
|
GbE × 1、FE × 1、2.4G/5G Wi-Fi、Bluetooth
|
USB3.0 OTG × 1、USB2.0 HOST × 1
|
SAI × 5、UART × 10、SPI × 3、PWM × 16、SDMMC × 1、ADC × 13、CAN × 2
|
BTB
|
Industrial
|
|
|
20
|
Core-1688JD4 | Core Boards |
BM1688
|
Octa-core 1.6GHz
|
16T
|
1080P H.265
|
1080P H.265
|
MIPI-CSI、TTL
|
HDMI2.0 × 1、MIPI-DSI × 1、LVDS × 1、BT.1120 × 1
|
GbE × 2、2.4G/5G Wi-Fi、Bluetooth、5G/4G
|
PCIe/SATA3.0 × 2、USB3.0 OTG × 2
|
SD3.0 × 3、I2C × 10、SPI × 4、I2S × 3、PWM × 19、CAN × 2
|
Goldfinger 260P
|
Commercial
|
Select at least two products for comparison
