RS-SRM120 Converged Server

High-Performance
RISC-V Processor

Supports 1080p video
encoding and decoding

High-Speed
Network Communication

Scalable to
Terabyte-Level Storage Capacity

High-Performance RISC-V Processor

Equipped with two high-performance RISC-V processors, the SG2042, featuring a dual-chip interconnect architecture.
This powerful design supports up to 128 cores running concurrently and is capable of mixed-precision computing with INT8, FP16, BF16, and FP32.

Massive Storage Capacity

With 8 x 3.5-inch / 2.5-inch SAS / SATA drive bays,
the device supports SATA 3.0 HDD / SSD expansion,
allowing for easy scaling up to terabyte-level storage capacity.
It also supports hot-swapping for quick replacements.

Supports Video
Encoding and Decoding

The server supports H.265 and H.264 video decoding at
1080p resolution with up to 9600 frames per second (fps),
and H.265 and H.264 video encoding at 1080p resolution
with up to 3600 frames per second (fps).

High-Speed
Network Communication

The server is configured with dual Gigabit Ethernet ports
for high-speed and stable network communication.
An independent IPMI management network interface
separates the management network from the business network,
ensuring secure and reliable network communication.

Supports multiple
operating systems

Supports operating systems such as Fedora, Ubuntu,
OpenKylin, OpenEuler, and Deepin,
meeting the needs of diverse scenarios.

Open Instruction Sets

Based on the international open-source RISC-V instruction set,
there is no authorization restriction, and it supports mainstream
operating systems, creating a truly open computing platform
and making innovation ubiquitous.

Comprehensive Expansion Interfaces

Specifications

RS-SRA120 Compute Server RS-SRB120 Storage Server RS-SRM120 Converged Server

Basic Specifications

Product form

2U rack server

Processor

Two SG2042 64-core RISC-V processors@2.0GHz

Computing accuracy

-

-　

INT8/FP16/BF16/FP32

Video decoding

-

-　

H.265 & H.264: 1080P@9600fps (Resolution: 8K/4K/1080P/720P/D1/CIF)

Video encoding

-

-　

H.265 & H.264: 1080P@3600fps (Resolution: 4K/1080P/720P/D1/CIF)

Memory

256GB (Eight RDIMM memory modules, each with a capacity of 32GB, and a maximum rate of 3200MT/s)

Video memory

-

-　

192GB LPDDR4X

Storage

Comes standard with two 1TB M.2 2280 NVME SSDs Supports eight 3.5/2.5-inch SAS/SATA hard drives and supports hot swapping

Comes standard with two 1TB M.2 2280 NVME SSDs Comes standard with eight 12TB 3.5-inch SATA hard drives, supporting hot swapping

Comes standard with two 1TB M.2 2280 NVME SSDs Supports eight 3.5/2.5-inch SAS/SATA hard drives and supports hot swapping

RAID

Supports RAID 0/1/10/5/50/6/60, etc

Comes standard with 1 disk array card, supports RAID 0/1/10/5/50/6/60, etc

Supports RAID 0/1/10/5/50/6/60, etc

Power

2 × 1300W hot-swappable power supplies, support 1+1 redundancy (Input: 200V AC ~ 240V AC)

Fan module

4 hot-swappable fans with N+1 redundancy

OS

Fedora 38 (Default installation)/Ubuntu 24.04/openKylin 1.0/openEuler 24.03/deepin 23

Size

748.0mm (L) × 433.4mm (W) × 87.2mm (H)

Weight

Net weight: 17.9kg, Total weight with package: 25.75kg

Environment

Operating Temperature: 10℃ ~ 40℃, Operating Humidity: 35% ~ 80%RH, Storage Temperature: -40℃ ~ 65℃, Storage Humidity: 20% ~ 90%RH

Interface

Internet

2 × Gigabit Ethernet (RJ45, service), 1 × Gigabit Ethernet (RJ45, IPMI management)

PCIe

6 × PCIe3.0

USB

5 × USB3.0 (One of them is inside the device)

VGA

2 × VGA

Manage serial ports

1 × RS232（DB9）
