Face X1 Face Recognition All-In-One PC
Face X1 adopts RK3399 six-core 64-bit CPU, equipped with aluminum CNC case, IPS high-end screen and wide dynamic binocular camera. It has powerful face recognition performance, high-efficiency recognition, stable and reliable operation, and open related material to facilitate the facial recognition project.
Six-core 64-bit Processor
Uses RK3399 six-core 64-bit“server-level”processor, frequency up to 1.8 GHz, integrates quad-core Mali-T860 GPU. It supports multi-format video coding and decoding, and has better processing performance.
Efficient Identification And High Accuracy
Supports various face recognition algorithms smoothly, and the response to detection speed is efficient. Recognition speed is less than 200 ms and recognition accuracy is more than 99.77%.
Support Multiple Recognition Modes
Maximum supports identify 100,000 face database and multiple recognition modes(1:1, 1: N, M: N) to realize multi-person recognition and detection at the same time easily.
Equipped with Management System
Equipped with face recognition program (APK), PC background management software and mobile phone management software (WeChat APP). They can be directly applied to the project by matching the whole machine.
Wide Dynamic Binocular Camera
Built-in wide dynamic binocular camera which with 1/2.7″CMOS light-sensitive chips, 2 million pixels(1920×1080), greater than 100dB wider dynamic range, 0.1LUX at F1.8 super low illumination. It's suitable for various complex light environment.
High-Quality IPS HD Screen
With 8-inch fully fitted IPS screen, 800x1280 resolution, full-view HD display, vivid color reproduction, clear and smooth picture. It supports multi-touch and with sensitive and stable touch.
Aluminum CNC Case
Adopts aluminum alloy high-precision CNC case, after 38 processes, surface oxidation treatment, fanless design, effective heat conduction, stable operation under high-temperature aging of 60℃ for 7x24 hours. IP54 protection to satisfy the indoor or outdoor operating requirements.
Convenient Installation
Face X1 can be installed not only wall mounted but also desktop mounted and column mounted, which is very convenient to install and can be used on various occasions.
Rich Expansion Interfaces
Supports Wiegand interface (26bit)/RS485 (switching through relay), LED driver interface (white light, infrared light), light sensor (I2C interface), 4G LTE network (optional), etc.
Applications
Face X1 can be applied in buildings, communities, campuses, construction sites, factories and other occasions that require access control, attendance, and face payment, etc.
-
Office
-
Village
-
School
-
Factory
-
MTR
-
Shop
Product parameters
![]()
| Specification |
| Size |
8-inch, full-view, IPS LCD screen
|
| Resolution |
800 × 1280
|
| Binocular Camera |
| Type |
RGB Camera
IR Camera
|
| Sensor |
1/2.7″CMOS
1/2.7″CMOS
|
| Pixel |
2 million pixels（1920×1080）
2 million pixels（1920×1080）
|
| Minimum illumination |
≥0.1LUX at F1.8
≥0.1LUX at F1.8
|
| Frame rate |
30fps
30fps
|
| Signal-to-noise ratio |
≥45dB
≥45dB
|
| Output format |
MIPI 8bit YUV422
MIPI 8bit YUV 422
|
| White balance |
Automatic
Automatic
|
| Wide dynamic |
≥100dB wider dynamic range suitable for various complex light environment
-
|
| Vertical wide angle |
|
| Horizontal wide angle |
|
|
Main Parameter |
| CPU |
RK3399 six-core 64-bit 1.8GHZ processor（Dual-core Cortex-A72+ Quad-core Cortex-A53）
|
| RAM |
2GB LPDDR4
|
| Storage |
16GB eMMC，Support TF card expansion
|
| Fill light |
White fill light, IR fill light, Red and green indicator light
|
| Wireless network |
2.4GHz WiFi, support 802.11 b/g/n protocol
3G/4G LTE network (optional)
|
| Wired network |
10 / 100M Ethernet
|
|
Interface |
| Wiegand interface |
Support Wiegand 26 (shared with RS485, switched by relay)
|
| USB |
USB 2.0 Host x 1、 USB 2.0 OTG x 1
|
| RJ45 |
RJ45（10 / 100M Ethernet）
|
| Power |
DC 5.5mm*2.5mm
|
|
Software Features |
| 1：N Face recognition |
99.7％ recognition accuracy
|
| Stranger detection |
Support
|
| Face anti-spoofing |
Support
|
| UI interface configuration |
Support
|
| Remote upgrade |
Support
|
| Deployment method |
Support LAN, public network use
|
|
Other |
| Power |
DC 12V-2A
|
| Power consumption |
22W MAX
|
| Operating temperature |
0℃～60℃
|
| Operating humidity |
10%～90%
|
| Size |
238 mm × 123.6 mm × 27 mm
|
| Installation |
Bracket fixed installation, Wall mounting installation
|
